SHACMAN 8×4 Loader Crane

Reliable Quality, Advanced Technology

12T-30T

Hoisting weight

228kw

Engine power

2100+4575+1400mm

Wheelbase

SHACMAN 8×4 Loader Crane

Reliable Quality, Advanced Technology

Hoisting weight

12T-30T

Engine power

228kw

Wheelbase

2100+4575+1400mm

Request a Quote

Features

Related Recommendations

Request a Quote

Features

high safety

The truck crane is equipped with a variety of safety devices and protective measures, such as limiters, anti-tipping devices, etc., to ensure safety during operation.

Easy to operate

The operation of the truck crane is relatively simple and can be easily mastered by professionally trained operators.

Strong load-bearing capacity

Truck mounted crane has large carrying capacity, and the maximum carrying capacity can reach tens of tons. The relevant models include 2 tons, 3.2 tons, 4 tons, 5 tons, 6.3 tons, 8 tons, 10 tons, 12 tons, 16 tons, 18 tons, 20 tons, 25 tons, 30 tons, 80 tons, 140 tons and many other options.

Fast and efficient

Compared with other lifting equipment, the installation and disassembly process of truck crane is faster and can be completed in a short time, thus greatly improving work efficiency.

Crane parameters
Maximum lifting weight	14000 -20000kg
Crane arm	4-5sections
Maximum lifting height	17-25m
Overall machine width, span	2.5 m*8.56m
Maximum elevation angle	0-75°
Rotation angle	360°
Hydraulic outriggers	Large span two-stage hydraulic telescopic outriggers
Maximum lifting moment	360kN·m
other 1. Multiple optional configurations (winch, flying arm) to meet personalized customization needs; 2. Compact structure, using high-strength steel, lighter weight of the whole machine; 3. Advanced hydraulic system to improve the boom extension speed, realize boom anti-shake and multi-action linkage and proportional action functions; 4. The whole vehicle is electronically controlled, and the wireless remote control system is standard for getting on and off the vehicle, making the operation more convenient; 5. Standard large-span two-stage hydraulic telescopic legs to ensure operation stability;
