JMC 5m³ Sewer Cleaning Truck

Reliable quality

2m³ Shimizu/3m³ Sewage

Volume

JX4D30D6H

Engine

3800mm

Wheelbase

JMC 5m³ Sewer Cleaning Truck

Reliable quality

Volume

2m³ Shimizu/3m³ Sewage

Engine

JX4D30D6H

Wheelbase

3800mm

Request a Quote

Features

Related Recommendations

Request a Quote

Features

Highly efficient cleaning and dirt suction capabilities

It uses a high-pressure water pump with powerful cleaning capabilities. It can quickly clean roads, pipes, septic tanks and other facilities, and effectively remove stubborn stains and sediments.

Easy to operate, high degree of automation

The cleaning and suction sewage truck is simple and convenient to operate. It has an automatic control system that can realize remote control and automatic cleaning, reducing the operating difficulty and labor intensity.

Multiple functions, one car for multiple uses

The cleaning and suction truck combines the functions of a high-pressure cleaning truck and a suction truck, and has multiple functions such as flushing, unblocking, suction, and reverse discharge. It can be equipped with different configurations according to needs, such as high-pressure cleaning with water sprinkling, high-pressure cleaning with suction, high-pressure cleaning with feces suction, etc., to achieve multiple uses of one vehicle and improve equipment utilization and operating efficiency.

Safe and reliable to ensure safe operation

The use of advanced safety protection devices, such as the automatic alarm system when there is no water, can ensure the safety of operators and prevent equipment from being damaged due to lack of water or other malfunctions.

Tank volume(m³)	5
Effective suction distance（m）	≥8
Inhalation time（min）	≤5
Unloading time（min）	≤5
Maximum vacuum of the system（MPa）	≤-0.09
use	It can be used to suck and clean up silt, sand, sewage, feces, gravel, broken bricks and other liquid and semi-liquid wastes in various ditches and sewers. It can also be used for the suction and transfer of wastewater and sediments in industries such as oil refining, steel, chemical industry and sanitation.
Other The tank body is made of high-quality carbon steel, the head is one-time die-cast, the tank body has a built-in partition, the rear cover can be opened, and it can be turned over and unloaded. The overall structure is simple, reliable, and has a large capacity. The interior of the tank body has been pre-treated and sprayed with rust primer for high-efficiency anti-corrosion. The vacuum pump, four-way valve and other suction system components are all made of well-known domestic brands, with strong suction and high efficiency. All gas circuit components are made of well-known domestic brands, with stable performance and reliable quality. This model uses a hydraulic control system. The operation is simple, and the opening and closing of the tank tail cover and the lifting and falling of the tank can be completed by pushing and pulling the handle. There is a hand washing device at the rear of the vehicle to store clean water, which can be used by the operator to wash after work. The product is equipped with an overflow valve and a full tank alarm function to prevent sewage and impurities from entering the suction system after the tank is full, thereby damaging the suction system. Its suction system is equipped with a vacuum pressure gauge, which can detect the internal pressure of the tank in real time and reflect the operating status of the system. There is a safety support rod at the lower end of the tank, which can play a role in safety support when the tank is lifted, inspected, and maintained.
